The FUEL offers the widest windrange and is designed to work in a huge variety of conditions - from mast-high waves to flat water.

A soft Dacron luff panel and a pre-shaped profile combine the smoothness of the FLOW with the drive of the FLASH. The 5-batten concept gives you confidence in high winds and controlled speed on flat water.
Combined with the outstanding durability that our brand is known for, the result is a sail built to perform session after session - no compromises.

BLACKLINE HD WINDOW

Super strong and light 4mil "Blackline HD" X-Ply window for perfect visibility. The black yarn reduces light reflections and distractions, resulting in a clearer view that simply allows you to ride better and safer.

ADAPTIVE WIND RELEASE ( AWR )

Discover our unique Clew System: Switch seamlessly between IN and OUT configurations to gain extra twist while maintaining a full front draft.
Combine with dual clew height options for complete control over your rig's handling and style. * Full technical breakdown below.

AEROFIT BOOM POSITIONING ( ABP )

Reduces open area at the leading edge to boost aerodynamic efficiency and wind range. Limits sail movement at the boom area for improved gust stability and faster rotations. (Open a minimum of 2 sections to mount boom).

LOAD CONTROL LAYOUT

A unique concept for defining the sail profile (from front to rear) using an interacting material mix to control load, flex and twist across the entire sail body. Rather than relying on singular load lines, the whole sail functions as one intelligent entity.

• Adaptive front section with custom load behaviour to support the individual sail characteristics best:
  Soft Dacron for smooth On/Off behaviour on the FLOW.
  5mil X-Ply for instand drive and agression on the FLASH.
  Double Dacron for balanced power and a blend of FLOW and FLASH on the FUEL.

• Light and medium stiff 4mil body for a neutral loading behavior and optimal strength-to-weight ratio. Ultra light 2.5mil sail top for reduced swing weight.

• Stiff 5mil X-Ply frame at the leech for clean air release, better twist control, and added structural strength.

The unmatched aerodynamics and fine-tuned material load distribution of our Intelligent Load Control concept deliver added agility, more top speed, improved release and mighty low-end, while extending the overall wind range.

POWER PANEL OUTLINE

Pairs a wide center outline with a short boom and narrow head. The "power panel" above the boom catches cleanest airflow for controlled drive, while the narrow head ensures clean top release. As a result you get an extented windrange with mighty low-end acceleration, excellent clew-first stability and a very balanced and light handling.

FREEFLOW BATTENS

Customised batten curves and batten angles adjusted to each sail sail optimise the sail behaviour in both riding and jumping. Stiffer battens above the boom lock the power forward and flatten the trailing edge to reduce drag in gusty conditions. An optimised 40mm batten width with panel overlap makes the sail perfectly symmetric and saves weight. Our new, shorter batten tensioners reduce swing weight even more.

INTEGRITY SHIELD CONCEPT

A lightweight protection concept engineered to maximize durability while eliminating unnecessary bulk. By combining targeted Kevlar reinforcements and tailored padding, high-wear areas are fully shielded without compromising the sail's weight or responsiveness.

Hydrophobic Kevlar Protection in high-wear areas to protect your sail while always keeping it light in the water.
Streamlined EVA-padded Tack Fairing for optimal impact protection at the board deck.

SMART RIGGING AIDS

Visual rigging guide with "Power" and "Control" markers to define your optimal downhaul trim. Pulley threading guide for quicker gear setup.

1) Pick your preferred mast
PATRIK RDM 100% CARBON CC: Quicker response, lighter, max performance.
PATRIK RDM 80% CARBON CC: Forgiving in chop/high wind, extra durability, budget-friendly. (RDM 60 not recommended).

Lighter riders below 60kg should consider picking the next softer mast and using a long extension for improved twist and release.
(Full performance is not guaranteed on third-party masts. Consult a PATRIK dealer before using non-PATRIK rig components.)

2) Set Aerofit Boom Positioning (ABP)
Open 2 ABP sections for optimal performance, height adjustment and a clean fit with most boom heads. If in doubt, or for added power, leave three ABP slots open.
(Height marker "0" is a good starting point for an 180cm tall rider.)

3) Choose your preferred AWR setting
Modifies release characteristics without altering sail profile or trim. Adjust on-the-fly while rigged. *

4) Set your personal downhaul tension
Set downhaul to find your preferred style (use outhaul for power adjustments). Pull until loose leech wrinkles are between the "power" and "control" markers in the top of the sail.
• Less downhaul: More forward drive, more lift, more top leverage.
• More downhaul: Softer release in top turns and big landings, more control.

5) Adjust the outhaul to set the sail's power level and directness
• Minimum setting: Batten above boom just flips with one hand; tip sits well in front of mast; sail touches boom. Maximum power and pumping ability.
• Optimal setting (+2cm tension): Batten tip is halfway behind mast; touches boom only in strong gusts. Neutral backhand, direct rotation, wide power range.
• Maximum setting (+3cm tension): Flat profile, extended high-end control, direct feel. Planing and pumping are compromised.

Important: Outhaul tension scales up and down with downhaul tension. Judge settings by overall sail shape, not spec box numbers alone.
